If you’re looking for a professional, commercial grade lamp
post light, this fitting should meet your criteria. It offers many unique
features including programmable modes, light output and option motion sensor
integration.
This solar powered light fitting is designed to attach to
the top of a column or lamp post. All aluminium construction, this vandal
resistant fitting is packed with features and unlike any other solar lamp post
light on the market at this time. It’s a good size at 55cm high and 59cm
diameter, so it looks proportional on a 3M or 4M column. Some of its many
features include a 18W LED lamp, offering 2,800 lumens using a total of 84
Cree® SMD2835 LEDs. You can select and store the desired LED colour temperature using the remote control. Choose from warm white (2,700k~3,000k) or daylight white (5,500k~6,000k). There is a pre-installed, integral,
large capacity, LifePO4 lithium battery within, and a 38W monocrystalline solar
panel built into the top of this fitting, covered with a secure, high strength,
tempered glass cover. Weather resistant to IP65 and vandal/impact resistant to
IK10. It also features an integral MPPT charge control system which enables the
lighting to come on automatically at dusk. Programmable options include choice of
illumination times (up to 12 hours), choice of LED power (dimmable), and the
option to integrate the PIR/motion detector. Set-up is via a remote control
(included). If the motion sensor feature is selected, lighting will be at 30% output.
But upon motion detection, lighting will increase to 100% output for a couple
of minutes after motion ceases. The PIR sensor can detect up to 4M with an
approximate 300-degree angle. Quick and easy installation with the included security
screws. There is a hidden on/off switch. In a dark location it’s capable of
projecting light outwards and downwards in a diameter of up to several meters.
This solar powered light is also Dark Skies Friendly and IDA Approved meaning that it does not contribute to light pollution. Colour of light output is white. Colour of product is black. Sold as a single
unit.
Applications
Perfect for entrances, car parks, housing estates. footpaths and driveways etc.
May be used in either a residential or commercial environment. Ideal for
ecologically sensitive locations minimizing impact on nocturnal wildlife such
as bat, turtles, frogs, and insects, etc.
Technical Specifications
Performance
Anti-theft/vandal resistant design.
Dark Skies Friendly (IDA Approved).
Upward light waste ratio (U.W.L.R.) is <1%.
Automatically illuminates from dusk to dawn (up to 12 hours).
Programmable features (via the included remote control).
Choice of LED/light output (dimmer option).
Choice of timed modes.
Choice of PIR/motion sensor mode with illumination at 30% output and 100%
output upon motion detection (until motion ceases). Reverts to 30% output
within approx. 2 minutes of motion ceasing.
The motion sensor has a range of up to approx. 15M (50’) and a detection angle
up to 300 degrees.
One or more fitting can be matched and grouped to operate from the same remote
control (if required).
Net weight is approx. 11.8KG.
Weather resistance rated to IP 65.
Vandal/impact resistance rated to IK10.
Certifications CB, CE, RoHS, LM79, LM80, ISO9001, ISO14001, ISO45001, BSCI, ADQCC approved & AD authorized.
Luminaire
84 No. super bright, high output, white coloured, Cree® SMD2835 LEDs.
2,800 lumens.
18W LED power.
High LED efficiency of 190 lm/W.
CRI >80.
User selectable LED colour temperature (2,700k~3,000k warm white or 5,500k~6,000k daylight white).
Other LED colour temperature option available by special
order.
All die-cast aluminium construction, no parts to rust.
Black powder coated finish (RAL 9011). Grey finish (RAL 7016) by special order.
Other colours available for large quantity orders only (white, brown, green or
any RAL colours).
Illumination pattern is approximately 360 degrees with light projected outwards
and downwards towards the ground.
Light distribution is up to 8M (26’) diameter (depending on column height).
The main body section of this fitting is approx. 55cm (21.5") high and a
diameter of approx.. 59cm (23”).
Battery
Supplied with a pre-installed LifeP04 3.2V lithium battery.
The battery capacity is 154WH 12.8V DC.
The battery has a typical lifespan of up to 10 years (6,000 cycles)
The battery is replaceable, when required.
Working temp. -15 deg. C ~ +70 deg. C.
Typical charge time is up to 4 hours.
Typical discharge time is > 24 hours.
Autonomy is up to 2~3 days (or up to 5 days in PIR/motion detector mode)..
Solar Panel
High quality, integrated, monocrystalline 38W 18V solar panel.
Solar cell efficiency > 22.5%.
Typical lifespan > 20 years.
The solar panel is neatly set into the top section of the light fitting and
protected by clear tempered glass.
Installation
Easily installed onto the top of a 76mm (3”) OD column or round post.
Fitting to alternative sized columns (e.g. 89mm) is possible with a tenon
adapter or spigot (available as an option).
Installation time is typically less than 5 minutes per fitting.
Spacing is at the owner/installer's discretion.
Notes
This product is a special order and is non-returnable except in the event of a
fault (during its warranty period) when the product, once returned will be
repaired or replaced.
The solar panel must be installed in a location where it can receive full
direct sunshine (when available) and set facing South at about a 45-60 degree
angle (where adjustment options allow). The solar panel must not be installed
in a shaded or part shaded location and never indoors. The standard
specifications of the system (particularly the solar panel Wattage and battery
capacity) may need to be adjusted. These components are determined by your
geographic location, power consumption (LED Wattage) and the total amount of
hours of illumination time required. Such changes to the standard specifications
may increase or decrease the cost shown. Please contact us for more information
or assistance. The illumination time is estimated and subject to various
factors including (but not limited to) geographic location, seasons,
temperature, weather conditions & location of product etc. The illumination
time of most solar lights can reduce during winter months when the weather is
poor, and the days are shorter. During this time, insolation hours decrease
accordingly. Shorter illumination time due to one or more of the above factors
does not define the product as being ‘defective’ or ‘not as described’ or 'not
fit for purpose'. All solar lights must be used in a dark location at
night-time otherwise they may not illuminate. Nearby strong lighting sources or
ambient lighting may affect the operation of a solar light. This does not
define the product as being 'defective' or 'not as described'. Please note, if
you do not install or use this product for several months the battery may
discharge naturally on its own. By allowing a battery to deep discharge it may
cause irreversible damage as the battery may then lose the ability to recharge
or hold a full charge. Although unlikely, we reserve the right to supply this
product with any minor alterations or minor changes to the specifications
(shown above by text description or by photographs) due to different supplies
or product batches received, incorporating such product changes made by the
manufacturer, without further notice. Descriptions, specifications, and photographs
are updated regularly but may not be current when minor changes to a product
have only recently been made.
